Powerbox - PBR-26D

Features

26 Channel 2.4GHz Receiver

Two independent redundant receiver circuits

Extreme interference rejection

Ultra-long range

No servo outputs; intended as receiver unit for PowerBox or FBL systems

Option of iGyro SAT

Integral telemetry / servo bus (P²BUS)

High-performance real-time telemetry

Reception quality and airborne battery voltage available via telemetry as standard

Auxiliary output can be configured as serial interface (S.BUS or SRXL)

Parameters for all functions can be set from the transmitter

Technical Data

Operating voltage

4.0V - 9.0V

Supported RC systems

CORE

Channels

26

Servo sockets

26

Servo signal resolution

4096 Steps

Integral gyro system

optional with iGyro SAT

Dimensions

48 x 25 x 10 mm

Weight

10g

Temperature range

-30°C to +85°C
